Precision is our ProfessionMitutoyo Uni Micrometer, Series 117, (interchangeable anvil)Measures tubing thickness, shoulderedge distance, rivet head height, etc. with interchangeable anvils (flat anvil, rod anvil, V-anvil).Supplied with Flat Anvil (201216)
Mitutoyo Uni Micrometer, Series 117, (interchangeable anvil)
Technical Data
Accuracy: Refer to the list of specifications.
Resolution*: .00005″/0.001mm or 0.001mm
Graduation**: .0001 or 0.01mm
Spindle face: Carbide tipped
Display*: LCD
Battery*: SR44 (1 pc.), 938882
Battery life*: Approx. 2.4 years under normal use
Dust/Water protection level*: IP65
*Digital models **Analog models
Function of Digital Model
Origin-set, Zero / ABS, Data hold, Data output,
inch/mm conversion (on inch/metric models only)
Function Lock
Alarm: Low voltage, Counting value composition error
Uni Micrometer, Series 117, (interchangeable anvil) | ||||
Code | Model | Range | Graduation | Price |
Metric | ||||
117-101 | ACM-25 | 0-25mm | 0.01mm (Flange:6.35) | 12,600.00 |
117-102 | ACM-50 | 25-50mm | 0.01mm (Flange:12.7) | 15,100.00 |
Inches | ||||
117-107 | ACM-1V | 0-1″ | 0.0001″ | 13,300.00 |
117-108 | ACM-2V | 1-2″ | 0.0001″ | 15,700.00 |
Cost: | $25 |
Free Shipping | We offer free shipping on orders over $30. Please check the free - shipping eligibility at checkout. |
Delivery Time: | It usually takes [3-5] business days for standard shipping. Please note that this is an estimated time frame and may be affected by local holidays, and unforeseen circumstances. |
